The Talaria STING RMX4 electric dirt bike was born to bring cutting edge performance to all riders. It features a CAD designed light weight frame design, a powerful electric motor delivering instant torque, transferred through an intelligent gear drive whilst operating extremely quietly.
Its compact well-balanced structure is very easy to maneuver, and requires minimal maintenance. All these features make STING an ideal off-road bike for more people than ever to enjoy the passion and thrill of off-road riding adventures

UPDATES ON THE LATEST MODELS

Bigger and Better Battery

The battery is 45Ah 60v (2700 Watt hours) consisting of high performance  LG 21700 (5000mah) cells that do not compromise battery life when putting out the extra range and power. This battery is an 18 percent improvement in range over the Surron X battery.

Gearbox

The Talaria uses a new and improved gearbox for its gear reduction with thickened mounts.  This makes the Talaria Sting more quiet and also more reliable (no broken belts) than Surron.  Instead of periodic changing of belts, the new gearbox requires changing of the oil every 3000 -5000 miles which is an easy and quick task (5 minutes).  You still need to do an oil change after the first 300 miles for break in.  The Talaria R comes with enough gear fluid to do your first oil change.

Included Upgrades:

• 220mm x 2.3mm thick rotors both front and rear (stock is 203mm x 2mm)
• Upgraded Brake Pads
• 4 Piston Hydraulic Brakes
• Improved throttle and tuning for smooth and predictable response
• The motor has an encoder (instead of hall sensors) for ultra smooth throttle response.
• Improved and strengthened Gear box (oil only needs to be changed every 3-5 thousand miles)
• IPM Motor Rated for High Power and 94% efficiency
• Thick 3.25 inch rear tire
• 45Ah 60v battery with LG 21700 Cells
• Rear Brake Rotor Protector
• Foot Peg Support Brace
• Full wrap sticker kit (not installed)
• Higo connectors on the ebrake shut off for easy disconnect
• OLED full function display
• Rear Brake Rotor Guard
• Talaria or Fast Ace fork (depending on supply) upgrades any of the forks it uses to customize them for this bike.

More Efficient and Reliable IPM Motor

We are very excited about the upgraded motor on this bike. This is an IPM (Interior Permanent Magnet) motor with bigger and better magnets and a far superior design to the stock Sting and Surron. This means better efficiency, better heat dissipation, and most importantly much more reliability than the stock motor.  Magnets coming loose or demagnetized and hall sensors coming loose were the biggest causes of motor failure in the Sting R MX4 / Surron.  This motor also includes a magnetic encoder which removes the need for hall sensors.  If you ever upgrade this bike with a more powerful controller this motor will handle much more power than the stock motor, and because it is more efficient you will get more power out of it. This motor will do higher RPMs than the older motors as well, and will give you a more robust power cu

Improved braking system

  Talaria understands that if they are going to upgrade their bike to be faster and more powerful they need to improve the braking system.  First of all they went with bigger and thicker rotors front and rear.  220mm x 2.3mm compared to the older 203mm x 2.0 mm. This gives you 20 percent more stopping power and heat dissipation.  The brake pads are upgraded to a more robust and squeakless pad.  4 levels of regenerative braking that you are able to adjust on the fly make the bike more efficient and less hard on the mechanical braking system. By using regenerative braking wisely you can increase your range by up to 5 percent and greatly reduce brake wear and tear.

Other Features Of Talaria Sting R MX4

12 Amp battery charger

4 position Regenerative braking which you can adjust while riding

145 pounds
